Description of Run down screen:

Run down screens offer a high capacity, cost effective method of solids/liquids separation utilizing stainless steel wedge wire as the screening medium.

Each unit is designed to suit the specific requirements for the customers. Consisting of a basic outer casing, which can be manufactured in mild steel or stainless steel, each unit incorporates a distribution chamber and feed weir; over which the effluent passes onto the wedge wire panel which is set at right angles to the flow to enable the separating process to commence.

The separated solids collect on the lower half of the screen to drain and compact, they then slide by gravity onto a solids discharge chute.

The extracted liquid passes through the wedge wire into an underflow collecting chamber, with a disposal outlet for either re-circulation or discharge.

Application of Run down screen

Food processing
Sewage & Water Treatment
Brewing, Distilling, Malting
Paper Processing
Chemicals
Plastics
Wood processing
Mineral Processing
Textile Finishing
Abattoirs
Tanneries
Agricultural
Poultry
Vegetable Processing

Features of Run down screen

Low Headroom - only 1.1 metres (44") tall for the 900mm arc length unit.
Energy Efficient - operates with no moving parts and with no energy input.
Space Efficient - treats up to 122 litres per second per square metre of floor space.
Quiet Operation - no moving parts means no mechanical or electrical vibrations.
Accurate Sizing - can be used for sizing solid particles down to 0.2mm (0.008").
Low Maintenance - the profile wire screen resists clogging by near-size particles, and the all-stainless steel construction ensures a long, corrosion-free installation.
Easy Screen Replacement - a typical screen can be replaced in 10 minutes with no tools.
